Fine Products

Industries we serve

  • Cables Industry
    • Halogen Free compounds (LSZH / HFFR / ZHFR)
    • General Purpose Insulation & Sheathing   (Power / Flexible / Flat cable)
    • Low Temperature PVC Compounds (-55⁰)
    • Heat Resistant Insulation / Sheathing (85⁰- 125⁰)
    • Insulation for Building Wires
    • Control Cable: RDSO
    • REACH & ROHS Compliant Compound
    • FR & FRLS
    • NBR PVC Compound
    • UV & Oil Resistant & as per UL Grade PVC
    • Anti Rodent & Anti Termite Compounds
    • PVC Master Batch
    • Molding Grade
  • Auto Industry
    • Automobile Compounds (JIS & DIN Standard)
OUR PRODUCT DATA SHEET

OUR PRODUCT DATA SHEET
  VARIATION AFTER AGEING
PROPERTIES SPECIFIC GRAVITY HARDNESS SHORE A THERMAL STABILITY  @
200⁰C		 TENSILE STRENGTH ELONGATION AT BREAK TENSILE STRENGTH ELONGATION AT BREAK VOLUME RESISTIVITY @
27°C		 LOSS OF MASS APPLICATION
UNIT – Nos Minutes N/mm²(min) % (min.) % % ohm.cm² mg/cm² (max)
TEST METHOD ASTM D-792 ASTM               D-
2240		 IS 5831 IS 10180(Part7) IS 10180 (Part7) IS 10180 (Part11) IS 10180 (Part11) IS
3396(Part10)		 IS 10810 (Part10)
Grade
FP11 1.45 ± .02 90 ± 2 90 12.5 150 ± 20 ± 20 5.5 X1013 >2 Type A Insulation
FP12 1.39 ± .02 90 ± 2 90 12.5 150 ± 20 ± 20 6.5 X1013 >2 Type A Insulation
FP13 1.38 ± .02 90 ± 2 90 12.5 150 ± 20 ± 20 5.5 X1013 >2 Type A Insulation
FP15 1.38 ± .02 91 ± 2 90 12.5 150 ± 20 ± 20 7.5 X1013 >2 Type A Insulation
FP16 1.39 ± .02 91 ± 2 90 12.5 150 ± 20 ± 20 9.5 X1013 >2 Type A Insulation
FP81 1.38 ± .02 95 ± 2 100 12.5 150 ± 20 ± 20 1.2 X1015 >2 Type B Insulation
FP82 1.44 ± .02 95 ± 2 100 12.5 150 ± 20 ± 20 1.2 X1015 >2 Type B Insulation
FP71 1.4 ± .02 90 ± 2 100 12.5 150 ± 20 ± 20 5 X1014 >2 Type C / HR Insulation
FP73 1.38 ± .02 90 ± 2 100 12.5 150 ± 20 ± 20 5 X1014 >2 Type C / HR Insulation
FP51 # 1.55 ± .02 92 ± 2 90 12.5 150 ± 20 ± 20 3.0 X1013 >2 FRLS
FP52 # 1.55 ± .02 92 ± 2 90 12.5 150 ± 20 ± 20 5.0 X1013 >2 FRLS
FP55 # 1.54 ± .02 90 ± 2 90 12.5 150 ± 20 ± 20 5.0X1013 >2 FRLS
FP42 A @ 1.55 ± .02 90 ± 2 55 12.5 150 ± 20 ± 20 N/A >2 FRST1 Sheathing
FP42 B @ 1.54 ± .02 92 ± 2 80 12.5 150 ± 20 ± 20 N/A >2 FRST2 Sheathing
FP21 1.55 ± .02 85 ± 2 55 12.5 150 ± 20 ± 20 N/A >2 ST1 Sheathing
FP33 1.54 ± .02 90 ± 2 80 12.5 150 ± 20 ± 20 N/A >2 ST2 Sheathing

1)    # Smoke Density Rating: 56% max/# HCL: 20% Max/#@ Temp. Index: 280° C Min/ #@ LOI: 31% Min.
2)    The above properties are indicative and represent the values as tested in our laboratories.
3)    Suitability of the product for particular application may be verified before use.

4)  Mentioned products are from a very General Category of products in our bucket list which can always be modified as per customer requirements. Advanced form of compounds like those related to UL grade and others can always be made available upon customer’s request.
